Pulse Duration 50-1ms Mechanical Shock Tester IEC62133 Battery Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | GAOXIN |
| Certification: | ISO |
| Model Number: | GX-5099-S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | Non-fumigation wooden box |
| Delivery Time: | 25 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20 sets per month |
|
Detail Information |
|||
| Work Platform: | 200 Mm×200 Mm | Maximum Load: | 10 Kg |
|---|---|---|---|
| Peak Acceleration: | 20---1500 G | Pulse Duration: | 50-1ms |
| Impact Wave: | Half Sin | Frequency Range: | 0.5---12KHz |
| High Light: | 1ms Pulse Duration Mechanical Shock Tester,IEC62133 Mechanical Shock Tester,ICP Battery Testing Equipment |
||
Product Description
Mechanical Shock
Product name: Mechanical Shock Test Machine
Model number: GX-5099-S
Equipment description
The system is in accordance with MIL - STD - 810, GJB - 150-18-86 and IEC68-2-27 standard. The system can capture impact wave quickly and exactly. The highest sampling rate can be up to 1 MHZ. You don't need to worry any missing even if the impact event is very small.
Specification
| Machine Parameters | |
| Work Platform | 200 mm×200 mm |
| Maximum Load | 10 kg |
| Peak Acceleration | 20---1500 G |
| Pulse Duration | 0.5---7ms |
| Volume(L×W×H) | 600×550×1950mm |
| Weight | 650 kg |
| Power | AC220V±10% 50Hz,1KVA & 0.5—0.7MPa |
| Measure System | |
| Input Channel | 2 |
| Sampling Frequency | 192KHz |
| Input Method | Voltage, electricity |
| Coupling Method | AC,DC,ICP |
| Pulse Duration | 50-1ms |
| Voltage Range | -10V--+10V |
| Impact Wave | Half Sin |
| Operation System | Microsoft Windows2000/XP |
| communication interface | USB2.0 |
| System Acceleration Sensor | |
| Brand | B&W |
| Model | 22100 |
| Output | Electric charges |
| Sensitivity | 3.93Pc/g |
| Frequency Range | 0.5---12KHz |
| Acceleration Range | ±2500G |
| Working Environment | -40~+160℃ |
| Working Requirement | |
| Power | 220V±10% 50Hz |
| Air Source | 0.5--0.8MPa |
IEC 62133 is one of the most important standards for exporting lithium-Ion batteries into global markets, including those used in IT equipment, tools, laboratory, consumer electronics and medical equipment. It specifies the requirements and testing for the safe operations of portable, sealed secondary cells and batteries made from them. There are currently two different versions: IEC 62133 2nd Edition and IEC 62133-2 1st Edition. The names look similar, but the versions are different with the requirements for a battery varying, depending on the market you wish to enter.
