DIN-53754 Leather TABER Abrasion Tester For Lab
Product Details:
| Place of Origin: | China |
| Brand Name: | Gaoxin |
| Certification: | ISO 2008 |
| Model Number: | GX-5027 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Non-fumigation wooden box |
| Delivery Time: | 15 working days |
| Payment Terms: | FOB Shenzhen, L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
|
Detail Information |
|||
| Name: | Abrasion Testing Machine | Test Standard: | DIN, TAPPI, ASTM |
|---|---|---|---|
| Applicable Industry: | Leather, Synthetic Leather | Counter: | LCD Digital |
| Rotating Speed: | 60rpm Or 72rpm | Load: | 250g, 500g, 750g, 1000g |
| Abrasive Wheel: | Diameter 2 Inch, Max. 52mm | Weight: | 20kg |
| Material: | Steel Sheet | Accessories: | High Precision Balance |
| Function: | Abrasion Resistance Test | ||
| High Light: | DIN-53754 Taber Abrasion Tester,Lab TABER Abrasion Tester,Leather Taber Abrasion Machine |
||
Product Description
Leather Fabric Rubber TABER Abrasion Tester Universal Testing Machine Lab Equipment
1. Quick Details
|
Alternative name |
Leather testing machine for abrasion resistance |
|
Function |
Test anti-abrasion capability of leather, fabric, glass, plastics |
|
Material: |
＃304 stainless steel |
|
Weight |
18kg |
|
Volume |
53×32×31cm |
|
Corresponding test standard |
DIN-53754,53799,53109,52347,TAPPI-T476,ASTM-D1044,D3884,ISO-5470 |
2. Description
The abrasion resistance tester is used to do the test of wear-resistant in leather, cloth, paint, paper,
flooring, plywood, glass and natural rubber. The method is using the standard size of specimen, then using
the regulated models of grinding wheel with loading weight to rub the specimen. Remove the specimen after
rotation to reach a centain number, and then observe the damage of the specimen or compare the weight
with the previous materials.
3. Features
a. Testing result is accurate
b. Structure is simple and easy to operate
c. Made according to related corresponding international standard.
d. Able to custom according to customer’s specific requirement.
4. Specifications
|
Model |
GX-5027 |
|
Specimen |
outside dia. Ø108mm; inside dia.Ø 8mm, 3mm(D) |
|
Grinding Wheel |
Ø2``(max.52mm)1/2``(W) |
|
Model of grinding wheel for different specimen |
CS17,CS10 for coating material CS17,H18,H22 for plastics CS32,CS33 plywood H18,H22,CS17 for fabrics |
|
Space Between Grinding Wheel |
63.5mm |
|
Grinding Wheel and Plate`s Space |
26±0.5 mm |
|
Rotating Speed |
60rpm or 72rpm |
|
Loading weight |
250g,500g, 1000g |
|
Counter |
LED,0~999999 |
|
Distance Between Specimen and Hose |
3mm |
|
Power |
AC220V,50HZ,3A |
