108L 270L Programmable Salt Spray Testing Chamber Salt Spray Chamber for Battery Industry Battery Environment
Product Details:
| Place of Origin: | China |
| Brand Name: | Gaoxin |
| Certification: | ISO 2008 |
| Model Number: | GX-3040 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Non-fumigation wooden box |
| Delivery Time: | 15 working days |
| Payment Terms: | FOB Shenzhen, L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
|
Detail Information |
|||
| Standard Basis: | IEC 68-2-11, IEC 68-2-52, JIS H 8502-1999, ASTM B 17, CNS 4158 H 2040 | Spraying Method: | Continuous Spraying |
|---|---|---|---|
| Test Chamber Temperature: | 35±1°C (NSS ACSS), 50±1°C (CASS) | Saturated Air Barrel Temperature: | 47±1°C (NSS ACSS), 63±1°C (CASS) |
| Spraying Volume: | 1.0~2.2ml/80cm²/h | PH Value: | 6.5~7.2 (NSS ACSS) 3.0~3.2 (CASS) |
| Tester Chamber Volume: | 108L, 270L, 480L, 800L, 1200L | Power Supply: | AC 220V |
| High Light: | Programmable Salt Spray Testing Chamber,270L Salt Spray Testing Chamber,108L Salt Spray Test Machine |
||
Product Description
Testing Equipment Of Corrosion Salt Fog Tester Chamber Programmable Salt Spray Testing Chamber
Touch Screen Battery Environment Chamber Salt Spray Corrosion Testing Chamber for NSS ACSS and CASS
Touch Screen Battery Environment Chamber Salt Spray Corrosion Testing Chamber for NSS ACSS and CASS
1.Product Name:Salt fog testing machine
2.Product Model:GX-3040
3.Description:The salt spray tester is used to test the corrosive resistance of products whose the surface was treated with paint, electroplating, inorganic and organic film, anode handling, anti-rust oil, etc.
4.Technical Parameter:
| Model | GX-3040-60 | GX-3040-90 | GX-3040-120 | GX-3040-160 | ||
|
Test room volume (L×W×H)cm |
60×40×45 | 90×60×50 | 120×80×60 | 160×100×60 | ||
| Outward volume(W×D×H)cm | 103×60×107 | 146×91×128 | 220×120×145 | 260×145×155 | ||
| Spraying mode | Continuous spray or programmable control intermittent spray( optional ) | |||||
| Material | Imported PVC board ＆P.P,depth of 5mm | |||||
| Test temperature | Neutral salt water test(NSS ACSS)35±1℃; Corrosion test (CASS)50±1℃ | |||||
| Saturated air barrel temperature | Neutral salt water test(NSS ACSS)47±1℃; Corrosion test(CASS)63±1℃ | |||||
| Spray quantity | 1.0~2.0 | |||||
| PH value |
Neutral salt water test(NSS ACSS)6.5~7.2; Corrosion test(CASS)3.0~3.2
|
|||||
| Test capacity(L) | 108 | 270 | 480 | 800 | ||
| Power | 1∮,AC220V,15A | 1∮,AC220V,20A | 1∮,AC220V,30A | |||
5.Standard configuration:
| Item | Quantity | Item | Quantity |
| Sample holder | 14 | Metering cylinder | 2 |
| Temperature indicator | 2 | Collector | 2 |
| Spray nozzle | 1 | Humidity cup | 1 |
| Operation manual | 1 | 5L Measuring cup | 1 |
| Solvent (Nacl) 500 g/bottle 2bottles |
PH test paper |
||
Dongguan Gaoxin Testing Equipment Co., Ltd.
Have independent production base plant.
Strong design and manufacturing capabilities.
Strong technical force and high-quality after-sales service.
Efficient after-sales service team.
A number of certification qualifications.
Factory outlets, so that customers benefit the most.
2003 Gaoxin was established in Dongguan.
2004 Started production in Xinhe Industry Park.
2005 Received manufacturing license from the Bureau of Standards,Metrology and Inspection.
Footwear, leather testing equipment series are successfully developed and into production.
2006 Certified by the authorization and the audit of ISO 9001 quality system.
Universal testing machine are successfully developed.
Set up R & D department.
2007 Certified by the authorization and the audit of ISO 14001 environment system.
Temperature and humidity test chamber into production.
2008 Nanchang branch was established.
The establishment of the export division, products enter the international market.
Paper products testing equipment series into production.
2009 Shenzhen branch was established.
Gaoxin was awarded "Good Faith Enterprise" qualification.
Awarded "China Famous Brand" qualification.
2010 Gaoxin Industries (HongKong) Co., Limited registered successfully.
Products have CE certification, successfully entered the European market.
2011 Certified as "High-tech Enterprises" by Technology Hall in Guangdong.
Chengdu branch was established.
2012 Shanghai branch was established.
Company started the 2rd production plant.
Four products successfully received the national patent.
2013 Products obtained CMC, SGS certification.
Battery testing machine series successfully received the national patent.
2014 Vietnam branch was established.
Changsha branch was established.
Alibaba orange power gymnastics training camp base.
2015 Received adward of annual outstanding instrument enterprises.
Battery testing machine series products identified as high-tech in Guangdong Province.
2016 Received awards Enterprise Innovation Prize.
2017 The company has annual sales of 100 million.
Battery testing equipment market share of 60%
