EN13287 Footwear Testing Machine For Outsole Slip Resistance

EN13287 Footwear Testing Machine For Outsole Slip Resistance

Product Details:

Place of Origin: China
Brand Name: Gaoxin
Certification: SATRA TM144, EN13287
Model Number: GX-5100

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: International standard wooden package
Delivery Time: 10-15 working days
Payment Terms: T/T
Supply Ability: 20 sets per month
Get Best Price Contact Now

Detail Information

Alternative Name: Shoes Slip Resistance Tester Product Model: GX-5100
Test Standard: SATRA TM144, EN13287 Operating System: Windows
Volume: 1010×670×1900 Mm Weight: About 250kg
High Light:

EN13287 Footwear Testing Machine

,

Outsole Footwear Testing Machine

,

5bar Footwear Testing Equipment

Product Description

Shoes Outsole Slip Resistance Test Equipment Friction Coefficient Footwear Testing Equipment





1. Product Model:GX-5100



2. Description:

The tester determines the coefficient of friction between footwear outsoles and flooring surfaces under conditions simulating those experienced at the most critical parts of a typical walking step. The method is applicable to all types of footwear, outsole units, heel top pieces(top lifts) and sheet soling materials, also most types of floorings including matting and stair nosings.



3. Test principle:

A footwear outsole and a flooring surface are brought into contact under a predefined force. After a short period of static contact the footwear and flooring surface are moved relative to one another at a constant speed. The force required to move the surface is measured and its value after a defined period divided by the contact force to give the coefficient of friction, under the particular conditions of the test. The test may be carried out dry or with water or other contaminant on the flooring surface.



4. Test standard: SATRA TM144, EN13287



5. Technical Parameter:

Maximum vertical pressure

1000N

Maximum level  pressure

1000N

Compression air

Minimum of 5 bar

Maximum test speed

500mm/s

Minimum test speed

50mm/s

Static contact time

0—5s

Vertical sensor

1.25KN

Level sensor

0.8KN×2

Computer

Applicable to software, including DVD record

Operating system

Windows XP

Display

15 inches, colorful LCD

Data query rate

1000 data point/second/channel

Data channels

4

Volume

1010×670×1900 mm

Weight

About 250kg

Power

240/220V -50Hz;220V- 60Hz;110V -60Hz; single phase



Footwear physical testing - Physical tests on shoe Resistance, abrasion, water resistance of shoes. The shoe : from its design to its marketing, including its manufacture, quality control and fit, CTC supports you in all stages of its production.



6.  Picture

EN13287 Footwear Testing Machine For Outsole Slip Resistance 0
