Product Details:

Place of Origin: Guangdong
Brand Name: GAOXIN
Certification: CE
Model Number: GX-5065

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Non-fumigation wooden box
Delivery Time: 15~20 days
Payment Terms: L/C, T/T
Supply Ability: 15 sets per month
Get Best Price Contact Now

Detail Information

Material: Stainless Steel Temperature Precision: ±0.5℃
Temperature Uniformmity: ±2℃ Rotating Speed: 60 R/min, Rotating 5hours
Driving Mode: Motor Drive Delay Function: 0~9999 Settable
Temperature Control Method: Intelligent P. I. D. Control Washing Solution: PH 11.0±0.1 And Heated To (45±2)℃
Soaking Time: 0.5h, The Solution Temperature Was Maintained At (45±2)℃ Material Of Inner Box: SUS#304 Stainless Steel
Supply Power: AC220V±10%, 50/60HZ Weight: Approx 300kg
High Light:

battery test equipment

,

battery testing machine

Product Description

The Battery Test Equipment for battery washing test and battery and cell test equipment

GB 31241 P.I.D. Control Battery Washing Testing Machine for Battery



Product Description



Battery washing test machine for the following battery in the alkaline solution can continue to charge and discharge washing, the battery should be non-explosive, fire is not qualified:

1. Lithium-ion battery pack for hand -held electronic products;

2. Lithium-ion battery packs for portable electronic products that may be carried our used in their pockets;

3. Other portable electronic products can be placed in the pocket to carry the battery pack;

4. Washing test of hand-held electronic products with non-user replaceable battery/ battery pack.



Specifications



Temperature range of inner box  Room temperature to 100℃ adjustable,commonly used temperature 45±2℃
Temperature precision  ±0.5℃
Temperature uniformmity  ±2℃
inner diameter  650mm
depth of wash box  550mm
Material of rotating plate  SUS#316 stainless steel
Material of inner box  SUS#304 stainless steel
Temperature control method  Intelligent P.I.D. control
Dimension  1300*850*2100mm(W*D*H)
Weight  Approx 300kg



Standard reference



GB 31241 - 2014



The Battery Test Equipment for battery washing test and battery and cell test equipment 0

The Battery Test Equipment for battery washing test and battery and cell test equipment 2
The Battery Test Equipment for battery washing test and battery and cell test equipment 3
The Battery Test Equipment for battery washing test and battery and cell test equipment 4
The Battery Test Equipment for battery washing test and battery and cell test equipment 5


The Battery Test Equipment for battery washing test and battery and cell test equipment 6
The Battery Test Equipment for battery washing test and battery and cell test equipment 7
The Battery Test Equipment for battery washing test and battery and cell test equipment 8
The Battery Test Equipment for battery washing test and battery and cell test equipment 9
The Battery Test Equipment for battery washing test and battery and cell test equipment 10
The Battery Test Equipment for battery washing test and battery and cell test equipment 11
1.How can we guarantee quality?
Our Products have passed the certification of China National Standard System. The products have been tested according to GB/UN/UL/IEC/SAE/ISO/TAPPI/AATCC/ASTM/EN/DIN/JIS. The company has a complete organizatinal structure and management system,through the ISO9001 quality management system, ISO14001 environmental management system certification.

2.What can you buy from us?
Our products include battery testing equipment, leather testing equipment, footwear testing equipment, tensile testing machine,
environmental test chamber, paper testing machine etc.

3.What details are required for a quotation?
What is the test standard
What product or material testing from this machine
What is the Test object size
What is you want the machine appropriate size

4.Can I make changes before I ship?
No,it can not change if machine finished

5.When will my order ship?
Need 10-45 workdays base on which type the the machine

6.How can I track my order?
We will send the schedule by each stage
