1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems

1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems

Product Details:

Place of Origin: China
Brand Name: Gaoxin
Certification: ISO 2008
Model Number: GX-5099

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: Non-fumigation wooden box
Delivery Time: 40 working days
Payment Terms: FOB Shenzhen,T/T,
Supply Ability: 50 sets per month
Get Best Price Contact Now

Detail Information

Working Table: 200*200mm Max Load: 10kg
Peak Acceleration: 20—1500G Pulse Duration: 0.5-7ms
Dimension: 600×550×1950mm(L×W×H) Electrical Requirements: AC220V±10% 50Hz,1KVA & 0.5—0.7MPa
High Light:

battery test equipment

,

battery testing machine

Product Description

1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems





1. Product Name: Battery Acceleration Shock Tester



2. Product model: GX-5099



3. Test standard:

UN38.3,UL1642,UL2054,QC/T 743-2006 , QC/T 744-2006,GB 8897.4-2002,IEC60086-4 ,SN/T1414, SN/T1413 , YD1628, GJB2374, QB/T2052, IEC62133-2012, SAE-J2464,GB31241



4.Shock testing machine Features:

  • User-friendly touching screen operation.Half sine, square waveform shock pulse programmers.High rigidity shock tables.
  • Half sine, square waveform shock pulse programmers.
  • High rigidity shock tables.
  • A full range of safety features.
  • Apply air and hydraulic pressurization, strong friction brake avoiding secondary shock.
  • Apply air spring suspension, hydraulic damping shockproof system, no shock impact on the surrounding, without foundation.



5.Specifications:



Main parameters
Working table 200*200mm
Max load 10kg
Peak acceleration 20—1500G
Pulse duration 0.5-7ms
Dimension(L×W×H) 600×550×1950mm
Net weight 650 kg
Electrical requirements AC220V±10% 50Hz,1KVA & 0.5—0.7MPa
Measurement system
Input channel 2 CH
Sampling frequency 192kHz
Input form Voltage, charge
Coupling method AC, DC, ICP
Pulse duration 50-1ms
Voltage range -10V~+10V
Shock waveform Half sine
The operating system Microsoft Win XP/Win7/Win 8
Interface USB 2.0
Sensor of acceleration
Brand B&W
Model 22100
Output mode Charge type
Sensitivity 3.93 pc/g
Frequency range 0.5-12Khz
Acceleration range ±2500G
Working environment -40~+160℃
Other description
Supply power AC380V±10%
Compressed air 0.5-0.8Mpa
Temperature RT~40℃
Humidity 25℃<85RH%
Reliability

The average failure rate≥5000 hours

Half-sine waveform generator for continuous use of not less than 8,000 times.



6. Product Picture

1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems 0



1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems 1



7.Company introduction:



Dongguan Gaoxin Testing Equipment Co., Ltd is a high tech company specialized in producing kinds of testing equipment which was established in 2007, located in manufacturing centre of China-Dongguan City where is close to Guangzhou city and Hong Kong.

Our advantages:

(1) Speciality in testing equipment

(2) Various products to choose from

(3) Accept customization

(4) Excellent after-sale service



1900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems 21900KG 380V 50HZ Half Sine Shock Test Equipment With Safety Protection Systems 3
